TRAVELS
- X AXIS:: 20"
- Y AXIS:: 18"
- Z AXIS:: 18"
SPINDLE SPEEDS:: 60-6000 RPM
SPINDLE TAPER:: NT40
TOOL SIZE::
30 TOOLS
TOOL WEIGHT:: 3.7" X 11.8" MAX. |
TABLE
WORKING SURFACE: 15.7" X 15.7"
MIN. INDEXING ANGLE:
1 DEGREE
DISTANCE BETWEEN SPINDLE CENTER
AND TABLE TOP:
2" - 20"
DISTANCE BETWEEN SPINDLE NOSE
AND TABLE
CENTER: 7" - 25"
LOAD ON PALLET: 880 LBS.
SPEED
CHANGE: STEPLESS
FEED - LEAST INCREMENT: 0.0001"
-
RAPID TRAVERSE: 590"
- CUTTING FEED: 0.01 - 200 IPM
TOOL CALL SYSTEM: RANDOM/BIDIRECTION, FIXED
ADDRESS
APC
- CHANGING SYSTEM: PARALLEL SHUTTLE
EQUIPPED WITH:
- FANUC
15M CONTROL
- CHIP CONVEYOR
- 15.75" SQUARE PALLETS
- 4TH AXIS CNC TABLE ROTATION
- ASSORTED TOOL HOLDERS
-
FLOOD COOLANT THRU THE SNOUT
NOTE: THE SPINDLE HAS BEEN REBUILT,
NEW SPINDLE
ORIENTATION SENSOR INSTALLED, REBUILT BY FANUC -
SERVO DRIVE BOARD AND NEW PCB BOARD INSTALLED.
MACHINE HAS BEEN
PAINTED. |
