Brand : TOSHIBA (Japan)
New In 1992
Condition : Excellent
Model : BTD-11R 16
NC Control : 777 TOSNUC
Boring Spindle Diameter : ¨ª 4.33¡± (110) (Milling: ¨ª 8.86¡± (225))
Axis Travel(X/Y/Z/W) : 79 x 59 x 57 x 19.7¡± (2000 x 1500 x 1450 x 500 mm)
Distance from Table Top to spindle Center : 0 ~ 59¡± (0~1500 mm)
Distance from Table Center to Spindle nose : 21.6 ~ 79¡± (550~2000 mm)
Table Work Space : 55 x 63¡± (1400 x 1600 mm)
Table Max Loading Capacity : 13900 lbs. (6300 kg)
Table Auto, Indexing : 0.0001o
Spindle Speed : 5~3000 min-1
Table (Pallet) Revolution Speed : 720 degrees /min
Spindle Taper Hole : 7/ 24 Taper No.50
Rapid Traverse : X,Y, Z- 472 IPM (12000 mm/min), W- 197 IPM (5000 mm/min)
Tool shank Type : ISO 50
ATC : 50 ea
Spindle Motor : AC 30/25 Hp (22 / 18.5 kW)
Machine Height : 156¡± (3970 mm)
Floor Space (LWH) : 236 x 200¡± (6000 x 5100 mm)
Machine Weight : 61730 lbs. (28000 kg)

 * Price will be followed upon request.
