TRAVELS
- X AXIS:: 42.5"
- Y AXIS:: 25.6"
- Z AXIS:: 24"
SPINDLE SPEEDS:: 20,000 RPM
SPINDLE TAPER:: BT-40
FEED RATE::
0.004-393 IPM
TOOL MAGAZINE CAP.:: 40 TOOLS
TOOL SIZE::
5" X 12.6"
TOOL WEIGHT:: 33 LBS.
CONTROL:: FANUC
15M |
EQUIPPED
WITH THE FOLLOWING:
- 40 TOOL ATC
- 2 APC (EACH PALLET -
47.2" X 23.6" )
- 20,000 RPM SPINDLE
- SPINDLE
WITH CERAMIC BEARINGS DUAL WINDINGS
20 HP/10 MIN.
- SPLASH
GUARD AROUND BED WITH AUTO DOOR FOR
HIGH SPEED SPINDLE
-
ADDITIONAL FLOOR SCRAPER TYPE CONVEYOR
- 1,050 FT. TAPE INFORMATION
- LINEAR ACCEL/DECEL AFTER CUTTING
- BELL SHAPE ACCEL/DECEL
AFTER CUTTING
- LOOK AHEAD TYPE ACCEL/DECEL BEFORE CUTTING
- HIGH SPEED PROCESSING FUNCTION
ADDITIONAL INFORMATION ON FILE. |
