Number
of spindles: 8
Chuck size: 8"
Max. swing of work: 8"
Max. long. travel tool slide: 8"
Max. travel lower front
& rear cross arms: 4.679
Max. feed lower front & rear
cross arms: 3.677
Max. travel upper front cross arm: 5.509
Max. feed upper front cross arm: 4.329
Max. travel upper rear
cross arm: 5.191
Max. feed upper rear cross arm: 4.078
Max.
long motion upper cross arm: 2.75
Max. travel lower front &
rear cross slides: 3.5
Max. feed lower front & rear cross
slides: 2.75
Max. travel upper rear cross slide: 3.5
Max.
feed upper rear cross slide: 2.75
Spindle RPM: 51-854
Floor
space: 80" x 165"
Weight: 28,500 lbs.
These are
general catalog specs only. |
|
