Model
600-C-P
Max. opening under head: 10"
Hot stamps items up to: 7"
Cylinder bore: 6" 0 - 800 degrees
Head stroke: 3"
Throat depth: 10"
Heating system: 9" x 12" head
4-550 watt cartridge heaters
2200 Watts total
Actuation: Anti-Tiedown 2-Hand Buttons standard
Electrical requirements: 110V AC
Compressed air requirements: 8 CFM for 1-1/2 Tons
at 10 cycles per minute at 60 lbs. air pressure
Heat controller: Solid state 0-750 degrees
Timer control: Solid state 0-5 seconds
Work table: 12" x 18"
Roll leaf feed: Sheridan Pinion type rollers
left to right air feed
Dimensions: 45" H x 30" W x 28" D
Weight: 500 lbs.
Print and manual available |
